Equinox Merlin 80w Multi Gobo Effect

MERLIN



Product Code: MERLIN

Brand: Equinox



Equinox Merlin 80w Multi Gobo Effect

Brand: Equinox

Equinox Merlin 80w Multi Gobo Effect

Product Code: MERLIN

£209.00

165 in stock

2 to 3 Working Days Delivery

Qty

PayPal Pay Later

Klarna

User Manual

Download now

Free Standard Delivery over £50

Spend another £50 to qualify




The Equinox Merlin 80W is a compact multi gobo barrel effect light designed to bring sharp moving projections, colour and energy to dancefloors, stages and event spaces. Powered by an 80W cool white LED and fitted with a mirrored barrel, it projects a spread of colourful gobo patterns across walls, ceilings and dancefloors, making it ideal for mobile DJs, weddings, parties, bars, nightclubs and live events.

Unlike a basic party light, the Merlin uses static gobos and colours with moving barrel projection to create a more structured visual effect. The 8 static gobos and colours plus open position give you a choice of looks, while the 4 degree beam angle per beam and 27 degree gobo flower coverage help produce crisp, defined patterns across the room. A manual focus adjustment on the rear of the fixture allows the projection to be sharpened to suit the throw distance and venue layout.

Control is flexible for both simple and programmed lighting setups. The Merlin can be used in automatic mode for quick plug and play operation, sound active mode for music triggered effects, or primary and secondary mode when linking multiple fixtures together. For more detailed control, DMX operation is available with 2, 6 or 9 channel modes, allowing the fixture to be integrated into a wider lighting rig with moving heads, pars, lasers and other DJ effects.

Movement is designed to give wide room coverage from a compact unit, with 180 degrees of pan and 360 degrees of tilt. The fixture also includes 0 to 100 percent dimming and variable strobe, giving extra control over intensity and show moments. The 4 button menu with OLED display makes setup straightforward, even in dark venues or mobile DJ environments where quick adjustments are important.

With a lightweight 2.5kg design, fan cooling, PowerTwist TR1 power input and 3-pin XLR DMX input and output, the Equinox Merlin 80W is practical for mobile rigs and venue installations. It is a strong choice for users looking for a compact LED gobo barrel effect that can deliver eye catching motion, crisp projection and reliable control without taking up much space.

Best for mobile DJs, party lighting, wedding entertainment, bars, clubs, school discos, live events and venues needing a compact 80W LED gobo effect with mirrored barrel movement and DMX control.

  • 80W cool white LED gobo barrel effect light
  • 7500K LED colour temperature
  • Mirrored barrel projects colourful moving gobos
  • 8 static gobos and colours plus open
  • Manual focus adjustment for sharper projection
  • 4 degree beam angle per beam
  • 27 degree coverage per gobo flower
  • DMX control with 2, 6 or 9 selectable channel modes
  • Auto, sound active and primary/secondary operation
  • 180 degree pan movement
  • 360 degree tilt movement
  • 0 to 100 percent dimming
  • Variable strobe effect
  • 4 button menu with OLED display
  • PowerTwist TR1 power input
  • 3-pin XLR DMX input and output
  • Fan cooled design
  • 80W power consumption
  • 100 to 240V, 50/60Hz power supply
  • Dimensions 314 x 283 x 162mm
  • Weight 2.5kg

MINI FAQ
Q: What type of lighting effect is the Equinox Merlin
A: The Merlin is a multi gobo barrel effect light that projects moving patterns and colours across walls, ceilings and dancefloors.

Q: Can the Equinox Merlin run without a DMX controller
A: Yes, it includes automatic and sound active modes for plug and play use, plus primary and secondary operation for linking fixtures.

Q: Can it be used with DMX
A: Yes, the Merlin supports DMX control with 2, 6 or 9 selectable channel modes using 3-pin XLR connections.

Q: What is the manual focus used for
A: The manual focus lets you sharpen the gobo projection to suit the distance between the fixture and the surface being lit.

Q: What is the Equinox Merlin best used for
A: It is best suited to mobile DJs, parties, weddings, school discos, bars, clubs and live events where compact moving gobo effects are needed.
