The Studiomaster CLUB XS10+ is a compact 10 input analogue PA mixer designed for live sound, rehearsal rooms, performers, small venues, schools, houses of worship and home recording setups. Built for users who need practical hands-on control without a large mixing console, it provides a strong balance of microphone inputs, stereo channels, effects, playback and recording functions in a portable format.

With 6 microphone input channels and 2 stereo input channels, the CLUB XS10+ is well suited to singers, acoustic acts, duos, small bands, presenters and mobile sound systems. The mic channels include gain control, 3-band EQ, compressor control, high-pass filtering and mute switching, allowing quick adjustment of vocals, instruments and speech sources during live use.

For music playback and simple recording, the mixer includes Bluetooth connectivity plus USB and SD card audio playback and recording. This makes it useful for backing tracks, interval music, rehearsals, event playback and capturing a stereo recording without needing a separate recorder. RCA phono playback and recording connections are also provided for analogue audio sources and external recorders.

Built-in DSP effects add extra polish for vocals and live performance, with reverb, delay and stereo effect options available from the onboard effects section. A DSP on and off footswitch socket allows performers or engineers to control effects more conveniently during a show, which is especially useful for singers, solo performers and small live setups.

The CLUB XS10+ also includes 2 auxiliary sends, balanced mic and line connectors, balanced XLR main outputs, jack outputs for auxiliaries and control room monitoring, plus headphone output for checking the mix. This gives the mixer enough flexibility for front of house sound, monitor feeds, recording, playback and small venue PA applications.

Key specifications include a mic channel frequency response of 10Hz to 20kHz, 80dB signal to noise ratio, 80Hz low cut, 12kHz high EQ, 2.5kHz mid EQ and 45Hz low EQ. The mixer operates from 100V to 240V mains power and measures 360 x 80 x 365mm with a 5kg weight, making it practical for portable rigs and fixed small sound systems.

Best for small bands, singers, acoustic performers, rehearsal rooms, schools, churches, community venues, mobile PA systems and users needing a compact 10 input mixer with Bluetooth, DSP effects, USB SD playback and recording.

• 10 input compact analogue PA mixer
• 6 microphone input channels
• 2 stereo input channels
• Bluetooth playback capability
• USB and SD card audio playback
• USB and SD card audio recording
• Built-in DSP effects including reverb, delay and stereo effects
• DSP effects on and off footswitch socket
• 3-band EQ on mic channels
• 2-band EQ on stereo channels
• Compressor control on mic channels
• High-pass filter on mic channels
• Mute switch on mic and line input channels
• 2 auxiliary sends for monitors or external effects
• Balanced mic and line connectors
• Balanced XLR main outputs
• Jack outputs for auxiliary and control room feeds
• RCA phono playback and recording connections
• Headphone output for monitoring
• Mic channel frequency response 10Hz to 20kHz
• 80dB signal to noise ratio
• Output levels up to +26dB balanced and +20dB unbalanced
• 100V to 240V power requirement
• Dimensions 360 x 80 x 365mm
• Weight 5kg

MINI FAQ
Q: What is the Studiomaster CLUB XS10+ best used for
A: It is ideal for small bands, solo performers, rehearsal rooms, schools, churches, presentations, small venues and compact PA systems.

Q: How many microphone channels does it have
A: The CLUB XS10+ has 6 microphone input channels plus 2 stereo input channels, giving 10 inputs in total.

Q: Does the CLUB XS10+ have Bluetooth
A: Yes, it includes Bluetooth playback capability, making it useful for backing tracks, background music and interval playback.

Q: Can it record audio
A: Yes, it supports USB and SD card audio recording, as well as USB and SD card playback.

Q: Does it include effects for vocals
A: Yes, the mixer includes onboard DSP effects such as reverb, delay and stereo effects, with a footswitch socket for convenient effects control.
