Citronic CX23 Active Crossover 2 / 3 Way

Brand: Citronic

Citronic CX23 Active Crossover 2 / 3 Way

Product Code: CX23

£76.00

49 in stock

2 to 3 Working Days Delivery

Qty

PayPal Pay Later

Klarna

Free Standard Delivery over £50

Spend another £50 to qualify

457 reviews on

Product Details

The CX23 is a 2-way stereo or 3-way mono active crossover designed to split frequencies so that low frequencies are delivered to the amp driving the sub cabinets and mid/top frequencies are delivered to the amp driving the mid/top frequency cabs. This type of system is more efficient and delivers more accurate sound quality, especially in larger PA systems.

2-way stereo, 3-way mono crossover
19" rack mountable
Butterworth filters - 18dB/octave
Continuously adjustable cutoff frequencies
40Hz ultra-low frequency cut
Phase invert function
Inputs and outputs via XLR

Power supply 115/230Vac, 50/60Hz (IEC)
Input impedance : balanced40k ohms
Input impedance : unbalanced20k ohms
Output impedance220 ohms
Crossover ranges : stereo50Hz-5kHz;750Hz-7.5kHz
Crossover ranges : mono50Hz-5kHz;750Hz-7.5kHz; 2kHz-20kHz
Filter slope 18dB/octave
Frequency response 20Hz-25kHz +0/-1dB
Signal to noise ratio> 90dB
THD0.006%
Dimensions 482 x 44 x 170mm
Weight 2.5Kg

Citronic CX23 Active Crossover 2 / 3 Way

Citronic CX23 Active Crossover 2 / 3 Way

£76.00
